Oil & Gas Equipment

Plunger - Piston Pumps

Plunger - Piston Pumps

SQP1000 Quintuplex Plunger Pump

  • Max. brake horsepower: 1000 BHP(745kW).
  • Max. rod load: 100,000 lbs (445,000N).
  • Stroke: 6” (152.4mm).
  • Max. speed: 450rpm.
  • Gear ratio: 4.61 : 1.
  • Overall dimensions: 50.7” x 75.1” x 33.5”.
  • Weight: 7,000 lbs (3,180kg).


STP350 Triplex Plunger Pump

  • Power end: model PG05, welded steel housing.
  • Fluid end: 5”, 4 1/2”, 4”, 3 3/4” plungers for different pressures and displacements.
  • Max. brake horsepower: 350 BHP (265kW).
  • Max. rod load: 110,000 lbs (489,412N).
  • Stroke: 5” (127mm).
  • Max. speed: 350rpm.
  • Weight: 7,000 lbs (3,180kg).


STP1000 Triplex Plunger Pump

  • Max. brake horsepower: 1000 BHP (750kW).
  • Max. rod load: 133,087 lbs (592,000N).
  • Stroke: 8” (203.2mm).
  • Max. speed: 300rpm.
  • Gear ratio: 5.043 : 1.
  • Overall dimensions: 79.2” x 55.51” x 40”.
  • Weight: 8,500 lbs (3,856 kg).
